Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 600 -
Suspension Rigid -
Motor 200W 65Nm mid-drive -
Battery integrated (Li-Ion) 36v - 14 Ah - 504 Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium e-Road frame, Central motor, Hydroformed Technology, Internal Cable Routing, Flat Mount Disc 12x142
Suspension Fork
Carbon Disc Fork, Internal Cable Routing, Flat Mount Disc 12x100
Drivetrain
Rear Derailleur
Shimano GRX 1x11s
Wheels
Rims
Megamo Road GR 700 - TLR
Brakes
Brakes
Shimano GRX
Motor & Battery
Motor
Megamo e-Gravel central motor 200W 65Nm
Battery
integrated (Li-Ion) 36v - 14 Ah - 504 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
