Megamo FLAME CRB 10 2026
2026 E-bike
Estimate price |
6,630$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 150mm -
Travel Rear 160mm -
Fork RockShox Psylo
-
Groupset XT, Deore -
Suspension Full -
Motor Bosch 750W 100Nm mid-drive -
Battery Bosch PowerTube 800 -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Carbon Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel: 170/160 mm
Suspension Fork
Rock Shox 35 Psylo Silver RC, 150mm Travel, 15x110mm BOOST, 1.8" Tapered, 44mm offset
Rear Shock
Rock Shox Deluxe Select R, 230x60mm
Drivetrain
Rear Derailleur
Shimano XT M8100, Shadow Plus 12-Speed
Shift Levers
Shimano Deore 6100 Speed Rapidfire Plus 12-Speed
Cassette
Shimano Deore 6100 10-51T
Crank
FSA Bosch Direct Mount Chainring 34t CL55 12-Speed, Crankset 320 165mm
Bottom Bracket
Bosch, press-fit
Wheels
Front Hub
Megamo Hubs, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST EBIKE+
Rear Hub
Megamo Hubs, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST EBIKE+
Rims
Megamo 29 SL 30 ASY - Micro, 30 mm Tubeless ready Aluminium rim
Tires
Maxxis Front: 29 x 2.5 Assegai, Rear: 29 x 2.4 Minion DHR II
Brakes
Brakes
Shimano MT520 hydraulic disc 4-Piston, 203mm
Cockpit
Stem
Satori New Ursa 35mm
Handlebar
Megamo Alloy Butted 31,8 x 780 mm, 12 mm Rise, 6º Back Sweep
Headset
Acros AZX-286R1 ZS56 blocklock 150º
Seat
Saddle
Fizik Terra Aidon X5
Seatpost
Megamo Ø 31,6mm telescopic seat post, remote adjustment S size 125 mm Drop / M size 150 mm Drop / L size 170 mm Drop
Motor & Battery
Motor
Bosch Performance Line CX, 5gen BDU384Y, Smart System / 100Nm 750W
Battery
Bosch PowerTube 800
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.459 mm | 1.398 mm | 1.348 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm |
| Front Center | 761 mm | 790 mm | 830 mm |
| Rake | 51 mm | 51 mm | 52 mm |
| Trail | 121 mm | 121 mm | 120 mm |
| Stack | 620 mm | 629 mm | 647 mm |
| Reach | 425 mm | 450 mm | 480 mm |
| Top Tube Length | 574 mm | 601 mm | 636 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 400 mm | 420 mm | 460 mm |
| Head Tube Angle | 64.6 ° | 64.6 ° | 64.6 ° |
| Head Tube Length | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1209 mm | 1238 mm | 1278 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
