Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 400 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New* Gravel AL 6061 Triple Butted, Hydroformed Technology, Internal Cable Routing, Flat Mount Disc 12x142
Suspension Fork
Carbon Disc Fork, Internal Cable Routing, Flat Mount Disc 12x100
Drivetrain
Rear Derailleur
Shimano RX-400 10s
Shift Levers
Shimano RX-400 Flat mount hydraulic disc
Cassette
Shimano HG50 11-36t 10s
Crank
FC 46-30t
Wheels
Rims
Megamo Gravel GR 700 - TLR
Tires
WTB Riddler 700 x 45c Tan Sidewall
Brakes
Brakes
Shimano RX-400 Flat mount hydraulic disc
Cockpit
Stem
Megamo FOV
Handlebar
Megamo Specific Gravel HB FOV Compact
Headset
FSA Orbit - Z 1-1/8" Semi Integrated
Seat
Saddle
Selle Italia Model X
Seatpost
Megamo 27,2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.524 mm | 1.536 mm | 1.516 mm | 1.531 mm | 1.553 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 572 mm | 584 mm | 606 mm | 631 mm | 657 mm |
| Rake | 50 mm | 49 mm | 51 mm | 49 mm | 50 mm |
| Trail | 74 mm | 72 mm | 66 mm | 68 mm | 67 mm |
| Stack | 529 mm | 550 mm | 570 mm | 600 mm | 632 mm |
| Reach | 347 mm | 358 mm | 376 mm | 392 mm | 407 mm |
| Top Tube Length | 494 mm | 515 mm | 545 mm | 575 mm | 600 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 415 mm | 500 mm | 530 mm | 570 mm | 590 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 105 mm | 125 mm | 145 mm | 175 mm | 210 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 992 mm | 1004 mm | 1026 mm | 1051 mm | 1078 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
