Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Apex -
Suspension Rigid -
Motor 200W 65Nm mid-drive -
Battery integrated (Li-Ion) 36v - 14 Ah - 504 Wh -
Drivetrain 1 × 12 -
Brakes SRAM Apex Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium e-Gravel frame, Central motor, Hydroformed Technology, Internal Cable Routing, Flat Mount Disc 12x142
Suspension Fork
Carbon Disc Fork, Internal Cable Routing, Flat Mount Disc 12x100
Drivetrain
Rear Derailleur
SRAM Apex1 1x12s
Shift Levers
SRAM Apex 1x12s
Crank
FSA 38T
Wheels
Rims
Megamo Gravel GR 700 - TLR
Tires
WTB Riddler 700 x 45c Tan Sidewall
Brakes
Brakes
SRAM Apex1 1x12s
Cockpit
Stem
Megamo FOV
Handlebar
Megamo Specific Gravel HB FOV Compact
Headset
FSA Tapered
Seat
Saddle
Selle Italia Model X
Seatpost
Megamo 30,9mm
Motor & Battery
Motor
Megamo e-Gravel central motor 200W 65Nm
Battery
integrated (Li-Ion) 36v - 14 Ah - 504 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.558 mm | 1.515 mm | 1.654 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm |
| Front Center | 607 mm | 611 mm | 615 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 61 mm | 54 mm |
| Stack | 581.05 mm | 584.99 mm | 636.6 mm |
| Reach | 372.84 mm | 386.16 mm | 384.77 mm |
| Top Tube Length | 540 mm | 560 mm | 580 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 470 mm | 520 mm | 570 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° |
| Head Tube Length | 160 mm | 160 mm | 210 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1053 mm | 1058 mm | 1062 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
