Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Advanced Composite frame, Full Internal Cable Routing, Flat mount disc 12x142
Suspension Fork
Carbon Advanced Composite fork, Full Internal Cable Routing, Flat mount disc 12x100
Drivetrain
Rear Derailleur
SRAM Red AXS 12s
Shift Levers
SRAM Red AXS
Cassette
SRAM Red AXS 10-33T
Crank
SRAM Red AXS 50-37T
Wheels
Rims
Zipp 353 NSW Carbon – Carbon – Hookless 45mm
Tires
Pirelli P ZERO™ Race TLR Classic 30 - 622 SPEEDCore 127 tpi
Brakes
Brakes
SRAM Red AXS
Cockpit
Handlebar
Carbon Full Integratted Internal Cable Routing: 90/400 (XS), 100/400 (S), 110/420 (M,L), 120/440 (XL)
Headset
Totally Internal Cable routing
Seat
Saddle
Selle Italia SLR Boost Superflow Carbon
Seatpost
Aerodinamic Advanced Carbon Seat Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.415 mm | 1.415 mm | 1.42 mm | 1.425 mm | 1.432 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Stack | 505 mm | 522 mm | 541 mm | 560 mm | 580 mm |
| Reach | 357 mm | 369 mm | 381 mm | 393 mm | 405 mm |
| Top Tube Length | 507 mm | 523 mm | 541 mm | 559 mm | 576 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 422 mm | 453 mm | 473 mm | 499 mm | 525 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 103 mm | 116 mm | 135 mm | 156 mm | 176 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
