Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Fork Fox Rhythm Float 32 -
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Track Full Carbon Construction FSC Technology BB92 Carbon Swingarm Boost 12x148mm
Suspension Fork
Fox 32 Rhythm, Remote Lockout, 15x110 Boost, Travel 100mm
Rear Shock
Fox Float DPS Performance Elite, 3 positions Remote Lockout control, Evol SV Megamo Custom Reb. Adj. Travel 100mm 190x40mm
Drivetrain
Rear Derailleur
SRAM SX Eagle 12s
Shift Levers
SRAM SX Eagle 12s
Cassette
SRAM SX Eagle 12s 11-50t
Crank
SRAM SX Eagle 12s 32t
Bottom Bracket
BB86/BB92, press-fit
Wheels
Rims
Ready GR 25 TR - 15x110 / 12x148 Boost
Tires
Maxxis Ardent Race 29x2,35 - Tubeless Ready, EXO, 3C Maxx Speed, Foldable, 120tpi, Pirelli Scorpion XC H 29x2,4 ProWall - Tubeless Ready, 120tpi
Brakes
Brakes
Shimano MT-500 Hydraulic Disc
Cockpit
Stem
Megamo Alloy 31,8
Handlebar
Megamo Alloy 31,8
Headset
Integrated Full Internal Cable Routing
Seat
Saddle
Selle Italia Model X Superflow
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.333 mm | 1.29 mm | 1.261 mm |
| Front Center | 696 mm | 721 mm | 752 mm | 785 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 93 mm | 92 mm | 91 mm | 92 mm |
| Stack | 592 mm | 592 mm | 605 mm | 624 mm |
| Reach | 420 mm | 444 mm | 469 mm | 495 mm |
| Top Tube Length | 559 mm | 584 mm | 610 mm | 643 mm |
| Seat Tube Angle | 76.7 ° | 76.7 ° | 76.7 ° | 76.7 ° |
| Seat Tube Length | 422 mm | 441 mm | 482 mm | 520 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 96 mm | 96 mm | 111 mm | 130 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1124 mm | 1149 mm | 1180 mm | 1213 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
