Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Travel Rear 100mm -
Fork Suntour XCT
-
Groupset Tourney, Altus -
Suspension Full -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE SPEED, 100mm suspension travel, material: aluminium, 29x2.25" max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
SR Suntour XCT30, Coil, 100mm suspension travel, 29x2.25" max. wheelsize
Drivetrain
Rear Derailleur
Shimano RD-M310-8
Front Derailleur
Shimano FD-TY700
Shift Levers
Shimano SL-M315-3 / Shimano SL-M315-8
Cassette
Sunrace CSM55.8, 11-32 teeth, 8 speed
Crank
Shimano TY301, 42-34-24 teeth, MAT Aluminium, 170 mm-S, 175 mm-M up
Bottom Bracket
FSA TH-7420ST, 68-124
Chain
Sunrace CNM84
Pedals
VP VPE-891
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA CC, 17mm inner width, material: aluminium
Spokes
Black steel
Tires
MERIDA K1080, 29x2.2", wire
Brakes
Brakes
Tektro HD-M275, hydraulic brake
Cockpit
Handlebar
MERIDA CC, material: aluminium, 690mm width, 15mm rise
Headset
FSA NO.10
Seat
Saddle
MERIDA Sport comfort
Seatpost
MERIDA CC, 27.2mm diameter, 15mm setback, material: aluminium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.646 mm | 1.61 mm | 1.588 mm | 1.559 mm | 1.532 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 628 mm | 649 mm | 663 mm | 683 mm | 704 mm |
| Rake | 47 mm | 51 mm | 53 mm | 57 mm | 60 mm |
| Trail | 86 mm | 82 mm | 76 mm | 72 mm | 69 mm |
| Stack | 614 mm | 623 mm | 635 mm | 644 mm | 654 mm |
| Reach | 373 mm | 387 mm | 400 mm | 413 mm | 427 mm |
| Top Tube Length | 558 mm | 579 mm | 599 mm | 619 mm | 640 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 382 mm | 448 mm | 486 mm | 532 mm | 583 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1071 mm | 1092 mm | 1106 mm | 1126 mm | 1147 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 698 mm | 755 mm | 789 mm | 829 mm | 869 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
