Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Fork Suntour XCE -
Groupset Tourney -
Suspension Hardtail -
Brakes JAK Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.SEVEN SPEED
Suspension Fork
Suntour XCE28
Drivetrain
Rear Derailleur
Shimano TY300, TOURNEY
Front Derailleur
Shimano TY300, TOURNEY
Shift Levers
Shimano ST-EF500
Cassette
Shimano CS-HG200-12-32, 7s
Crank
Shimano TY301
Bottom Bracket
Cartridge Bearing
Chain
CN-7s
Pedals
Plastic VPE-891
Wheels
Front Hub
Alloy Disc, Quick Release
Rear Hub
Alloy Disc, Quick Release
Rims
MERIDA double D, alloy
Tires
CST PATROL (27.5x2.25")
Brakes
Brakes
Jak-7 Mechanical Disc
Cockpit
Handlebar
MERIDA Comp
Headset
A-Head OS
Seat
Saddle
Merida Comfort DDK-200
Seatpost
MERIDA Speed
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.586 mm | 1.561 mm | 1.566 mm | 1.563 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm | 302 mm |
| Front Center | 618 mm | 629 mm | 633 mm | 643 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 85 mm | 85 mm | 81 mm | 81 mm |
| Stack | 593 mm | 598 mm | 609 mm | 619 mm |
| Reach | 374 mm | 383 mm | 389 mm | 396 mm |
| Top Tube Length | 550 mm | 560 mm | 575 mm | 585 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1042 mm | 1053 mm | 1057 mm | 1068 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 53 mm | 53 mm |
| Standover Height | 650 | 686 mm | 731 mm | 764 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
