Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY TFS III, material: aluminium, 700x50C max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Suntour NEX DS, Coil, 63mm suspension travel, 700x50C max. wheelsize
Drivetrain
Rear Derailleur
Shimano RD-M310-7
Front Derailleur
Shimano FD-TY510-3
Shift Levers
Shimano ST-EF500-L / Shimano ST-EF500-7R
Cassette
Shimano CS-HG200-7, 12-32 teeth, 7 speed
Crank
Shimano TY301, 48-38-28 teeth, MAT Aluminium, 170 mm-XXS/SM, 175 mm-ML up
Bottom Bracket
Shimano BB-UN101 73-123
Chain
SunRace CNM 84
Pedals
VP VPE-891
Wheels
Front Hub
Shimano TX505 / Shimano TY505-7, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505 / Shimano TY505-7, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA CC, 17mm inner width, material: aluminium
Spokes
Steel UCP
Tires
Front: MERIDA K1171, 700x40C, wire, Rear: MERIDA K1171, 700x40C, wire
Brakes
Brakes
Shimano M375
Cockpit
Stem
MERIDA COMP TK, material: aluminium, 25.4mm diameter, 7? stem angle, 100 mm all sizes
Handlebar
MERIDA CC, material: steel, 620mm width, 30mm rise
Headset
MERIDA M2345
Seat
Saddle
MERIDA Cross Sport
Seatpost
MERIDA TK
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.602 mm | 1.606 mm | 1.617 mm | 1.643 mm |
| Front Center | 630 mm | 634 mm | 645 mm | 653 mm |
| Rake | 42 mm | 42 mm | 42 mm | 41 mm |
| Trail | 79 mm | 76 mm | 76 mm | 74 mm |
| Stack | 620 mm | 631 mm | 645 mm | 667 mm |
| Reach | 387 mm | 393 mm | 399 mm | 406 mm |
| Top Tube Length | 565 mm | 580 mm | 590 mm | 610 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 130 mm | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1081 mm | 1085 mm | 1096 mm | 1104 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 713 mm | 748 mm | 782 mm | 817 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
