Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY TFS III, material: aluminium, 700x50C max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Suntour NEX HLO, Coil, 63mm suspension travel, Lockout, 700x48C max. wheelsize
Drivetrain
Rear Derailleur
Shimano CUES U3020, SGS
Front Derailleur
Shimano CUES U4000
Shift Levers
Shimano CUES U4000
Cassette
Shimano LG300, 11-36 teeth, 9 speed
Crank
Shimano CUES U4000, 40-26 teeth, 170 mm-XXS/XS/S, 175 mm-M/XL
Bottom Bracket
Shimano BB-UN101, 73mm
Chain
KMC xGlide
Pedals
VP VPE-891
Wheels
Front Hub
Shimano QC300 / Shimano QC300-HM, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano QC300 / Shimano QC300-HM, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TK, 20mm inner width, 17mm height, material: aluminium
Spokes
Black stainless
Tires
Front: Maxxis Overdrive Excel, 700x40C, wire, reflective stripe, Silkshild, Rear: Maxxis Overdrive Excel, 700x40C, wire, reflective stripe, Silkshild
Brakes
Brakes
Shimano MT200, 2 piston
Cockpit
Stem
MERIDA COMP TK, material: aluminium, 31.8mm diameter, adjustable, XXS/XS/S/M: 95 mm, L/XL: 110 mm
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
MERIDA M2346 Neck
Seat
Saddle
MERIDA Cross Sport
Seatpost
MERIDA EXPERT, 30.9mm diameter, 15mm setback, XXS, XS: 300mm, S, M: 350mm, L, XL: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.606 mm | 1.617 mm | 1.643 mm |
| Front Center | 634 mm | 645 mm | 653 mm |
| Rake | 42 mm | 42 mm | 41 mm |
| Trail | 76 mm | 76 mm | 74 mm |
| Stack | 631 mm | 645 mm | 667 mm |
| Reach | 393 mm | 399 mm | 406 mm |
| Top Tube Length | 580 mm | 590 mm | 610 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1085 mm | 1096 mm | 1104 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 748 mm | 782 mm | 817 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
