Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Shimano -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY L TFS III, material: aluminium, 700x50C max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Suntour NEX HLO, Coil, 63mm suspension travel, lockout, 700x50C max. wheelsize
Drivetrain
Rear Derailleur
Shimano ESSA RD-U2000-8, GS
Shift Levers
Shimano ESSA SL-315-8R
Cassette
Shimano CS-HG400-8, 11-45 teeth, 8 speed
Crank
Shimano ESSA FC-U2001 40 teeth, MAT Aluminium, 170 mm-XXS/XS/S, 175 mm-M up
Bottom Bracket
Shimano BB-UN101 73-123
Chain
KMC Z8.3
Pedals
VP VPE-891
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA CC, 17mm inner width, material: aluminium
Spokes
Black steel
Tires
MERIDA K1171, 700x40C, wire
Brakes
Brakes
Tektro M275, hydraulic brake
Cockpit
Handlebar
MERIDA CC, material: aluminium, 660mm width, 25mm rise
Headset
MERIDA M2345
Seat
Saddle
MERIDA Cross Sport
Seatpost
MERIDA TK, 27.2mm diameter, 13mm setback, 40mm seatpost suspension travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.623 mm | 1.602 mm | 1.606 mm | 1.617 mm | 1.643 mm |
| Front Center | 625 mm | 630 mm | 634 mm | 645 mm | 653 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 41 mm |
| Trail | 79 mm | 79 mm | 76 mm | 76 mm | 74 mm |
| Stack | 620 mm | 620 mm | 631 mm | 645 mm | 667 mm |
| Reach | 382 mm | 387 mm | 393 mm | 399 mm | 406 mm |
| Top Tube Length | 560 mm | 565 mm | 580 mm | 590 mm | 610 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 130 mm | 130 mm | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1076 mm | 1081 mm | 1085 mm | 1096 mm | 1104 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 639 mm | 639 mm | 639 mm | 639 mm | 639 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
