Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NX 1
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY L TFS III, material: aluminium, 700x50C max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Suntour NX1-DS-LO-700C-63, Coil, 63mm suspension travel, Lockout, 700x50C max. wheelsize
Drivetrain
Rear Derailleur
Shimano CUES U6020 10S
Front Derailleur
Shimano CUES U6010
Shift Levers
Shimano CUES U6000
Cassette
Shimano LG300, 11-39 teeth, 10 speed
Crank
Shimano CUES U4010, 46-30 teeth, 170 mm-XXS/XS/S, 175 mm-M/XL
Bottom Bracket
Shimano MT501
Chain
KMC xGlide
Pedals
VP VPE-891
Wheels
Front Hub
Shimano QC300 / Shimano QC300-HM, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano QC300 / Shimano QC300-HM, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TK, 20mm inner width, 17mm height, material: aluminium
Spokes
Black stainless
Tires
Front: Maxxis Overdrive Excel, 700x40C, wire, reflective stripe, Silkshild, Rear: Maxxis Overdrive Excel, 700x40C, wire, reflective stripe, Silkshild
Brakes
Brakes
Shimano MT200, 2 piston
Cockpit
Stem
MERIDA COMP TK, material: aluminium, 31.8mm diameter, adjustable, XXS/XS/S/M: 95 mm, L/XL: 110 mm
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
MERIDA M2346 Neck
Seat
Saddle
MERIDA Cross Sport
Seatpost
MERIDA EXPERT, 30.9mm diameter, 15mm setback, XXS, XS: 300mm, S, M: 350mm, L, XL: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.602 mm | 1.606 mm | 1.617 mm |
| Front Center | 630 mm | 634 mm | 645 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 79 mm | 76 mm | 76 mm |
| Stack | 620 mm | 631 mm | 645 mm |
| Reach | 387 mm | 393 mm | 399 mm |
| Top Tube Length | 565 mm | 580 mm | 590 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 140 mm | 155 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1081 mm | 1085 mm | 1096 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 639 mm | 639 mm | 639 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
