Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Motor MAHLE 40Nm hub-drive -
Battery Mahle B1-D, 250Wh -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eSILEX LITE, material: aluminium, 700x45C / 700x42C (with fender) / 27,5x47C max. wheelsize, 100x9/135x9mm axle standard, BSA bottom bracket standard, MUK 40 Hanger
Suspension Fork
MERIDA SILEX CF2, Tapered, material: carbon, 700x42C max/ 700x35C (with fender) max 50mm for 650B max wheelsize
Drivetrain
Rear Derailleur
Shimano GRX400
Front Derailleur
Shimano GRX400
Cassette
Shimano CS-HG50, 11-36 teeth, 10 speed
Crank
Shimano GRX600, 46-30 teeth, 170 mm-XS/S, 172,5 mm-M, 175 mm-L/XL
Bottom Bracket
Shimano BSA
Chain
KMC e10s
Wheels
Front Hub
VP CLK170F, 100x12mm width front hub, 32 spoke holes, centerlock
Rear Hub
VP CLK170F, 100x12mm width front hub, 32 spoke holes, centerlock
Rims
MERIDA COMP SL, 17mm inner width, 22mm height, material: aluminium
Spokes
Black stainless
Tires
Maxxis Rambler, 700Cx40, fold, EXO
Brakes
Brakes
Shimano GRX400, 2 piston
Disk Rotors
Shimano RT10 / Shimano RT26, 160 mm
Cockpit
Stem
MERIDA EXPERT IR, material: aluminium, 31.8mm diameter, 5° stem angle, 80 mm
Handlebar
MERIDA EXPERT GR, material: aluminium, 400mm (XS/S), 420mm (M), 440mm (L/XL)
Headset
VP MH-P16
Seat
Saddle
MERIDA COMP CC, V-mount
Seatpost
MERIDA EXPERT, material: aluminium, 30.9mm diameter, 0mm setback
Motor & Battery
Motor
Mahle X35+ Hub Engine, 40Nm
Battery
Mahle B1-D, 250Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.51 mm | 1.5 mm | 1.51 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 623 mm | 634 mm | 645 mm | 654 mm |
| Rake | 46 mm | 45 mm | 45 mm | 45 mm |
| Trail | 78 mm | 76 mm | 73 mm | 69 mm |
| Stack | 586 mm | 602 mm | 618 mm | 634 mm |
| Reach | 389 mm | 400 mm | 411 mm | 421 mm |
| Top Tube Length | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 160 mm | 175 mm | 190 mm | 205 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1049 mm | 1060 mm | 1071 mm | 1081 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 772 mm | 790 mm | 809 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
eSILEX 400 is a Merida E Esilex model. There are 3 e-bikes that carry this model name.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel e-bikes average price
According to our calculations, the average cost of a Gravel e-bike that is reliable is 3642$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2022 and its price was 3649$. Doing a quick comparison, we notice that eSILEX 400 price is 0.19% more expensive than the average cost of a Gravel e-bike.
eSILEX 400 components
Fork material
When it comes to the fork, this e-bike has a carbon one, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the eSILEX 400 e-bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida eSILEX 400 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
