Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Motor MAHLE 40Nm hub-drive -
Battery Mahle B1-D, 250Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eSILEX+ LITE, material: aluminium, 700x45C / 700x42C (with fender) / 27,5x47C max. wheelsize, 100x9/135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
MERIDA SILEX CF2, Tapered, material: carbon, 700x42C max/ 700x35C (with fender) max 50mm for 650B max wheelsize
Drivetrain
Rear Derailleur
Shimano GRX812
Cassette
Shimano M5100, 11-42 teeth, 11 speed
Crank
Shimano GRX600, 40 teeth, 170 mm-XS/S/SM/ML, 175 mm-L/XL
Bottom Bracket
Shimano BSA
Chain
KMC e11s
Pedals
VP VPE-891
Wheels
Front Hub
VP CLK170F, 100x12mm width front hub, 28 spoke holes, Centerlock
Rear Hub
VP CLK170F, 100x12mm width front hub, 28 spoke holes, Centerlock
Rims
MERIDA EXPERT CX, 19mm inner width, 24mm height, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Black stainless
Tires
Front: Maxxis Rambler, ShieldWall / TLR, 650Bx47, Rear: Maxxis Rambler, ShieldWall / TLR, 650Bx47
Brakes
Brakes
Shimano GRX600, 2 piston
Cockpit
Stem
MERIDA EXPERT IR, material: aluminium, 31.8mm diameter, 5° stem angle, 80 mm
Handlebar
MERIDA EXPERT GR, material: aluminium, 400mm (XS/S), 420mm (M), 440mm (L/XL)
Headset
VP MH-P16
Seat
Saddle
MERIDA COMP CC, V-mount
Seatpost
MERIDA EXPERT CC, material: carbon, 30.9mm diameter, 0mm setback
Motor & Battery
Motor
Mahle X35+ Hub Engine, 40Nm
Battery
Mahle B1-D, 250Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.51 mm | 1.5 mm |
| Front Center | 623 mm | 634 mm | 645 mm |
| Rake | 46 mm | 45 mm | 45 mm |
| Trail | 71 mm | 69 mm | 66 mm |
| Stack | 586 mm | 602 mm | 618 mm |
| Reach | 389 mm | 400 mm | 411 mm |
| Top Tube Length | 545 mm | 560 mm | 575 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° |
| Head Tube Length | 160 mm | 175 mm | 190 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1049 mm | 1060 mm | 1071 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 772 mm | 790 mm | 809 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
eSILEX+ 600 completes the Merida E Esilexplus model. There are 3 e-bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel e-bikes average price
According to our calculations, the average cost of a Gravel e-bike that is reliable is 3642$. However, even though the average price of a Gravel e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 3832$. Comparing the average cost of a Gravel e-bike to this one, you will see that eSILEX+ 600 price is 5.22% higher.
Overview of components
Fork material
The fork on this e-bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the eSILEX+ 600 model has aluminum wheels. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida eSILEX+ 600 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Merida eSILEX+ 600 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
