Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Motor MAHLE 40Nm hub-drive -
Battery Mahle B1-D 250Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eSILEX LITE II, material: aluminium, 700x45C / 700x42C (with fender) / 27,5x47C max. wheelsize, 100x9/135x9 mm axle standard, BSA bottom bracket standard
Suspension Fork
MERIDA SILEX CF2, carbon, max. 700x42C / 700x35C (with fender) / max. 50x650B wheelsize
Drivetrain
Rear Derailleur
Shimano GRX812
Cassette
Shimano M5100, 11-42 teeth, 11 speed
Crank
Shimano GRX600, 40 teeth, 170 mm-XS/S/SM/ML, 175 mm-L/XL
Bottom Bracket
Shimano RS500 BSA
Chain
KMC e11s
Pedals
VP VPE-891
Wheels
Front Hub
VP CLK170F, 100x12 mm width front hub, 28 spoke holes, Centerlock
Rear Hub
VP CLK170F, 100x12 mm width front hub, 28 spoke holes, Centerlock
Rims
MERIDA EXPERT CX, 19 mm inner width, 24 mm height, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Black stainless
Tires
Maxxis Rambler, 650Bx47, ShieldWall / TLR
Brakes
Brakes
Shimano GRX600, 2 piston
Cockpit
Stem
MERIDA EXPERT IR II, material: aluminium, 31.8 mm diameter, 5° stem angle, 80 mm all sizes
Handlebar
MERIDA EXPERT GRII, material: aluminium, 400 mm (XS/S), 420 mm (M), 440 mm (L/XL)
Headset
MERIDA 8158
Seat
Saddle
MERIDA COMP CC, V-mount
Seatpost
MERIDA EXPERT CC, material: carbon, 30.9 mm diameter, 0 mm setback
Motor & Battery
Motor
MAHLE X35+ Hub Engine, 40Nm
Battery
Mahle B1-D 250Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.511 mm | 1.513 mm | 1.511 mm | 1.51 mm | 1.512 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 611 mm | 623 mm | 634 mm | 645 mm | 654 mm |
| Rake | 45 mm | 46 mm | 45 mm | 45 mm | 45 mm |
| Trail | 82 mm | 78 mm | 76 mm | 73 mm | 69 mm |
| Stack | 565 mm | 581 mm | 597 mm | 613 mm | 629 mm |
| Reach | 374 mm | 384 mm | 395 mm | 406 mm | 416 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 145 mm | 160 mm | 175 mm | 190 mm | 205 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1032 mm | 1044 mm | 1055 mm | 1066 mm | 1076 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 748 mm | 767 mm | 785 mm | 804 mm | 830 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
eSILEX+ 600 is a Merida E Esilexplus model. There are 4 e-bikes that carry this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel e-bikes average price
If you want to purchase a solid Gravel e-bike, it is important to know that the average cost is 3642$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
eSILEX+ 600 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The eSILEX+ 600 2024 e-bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The eSILEX+ 600 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
eSILEX+ 600 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
