Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Motor MAHLE 40Nm hub-drive -
Battery Mahle B1 248 Wh, integrated -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eSPEEDER LITE II, material: aluminium, 700x45C / 700x42C (with fender) / 27,5x47C max. wheelsize, 100x9/135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
MERIDA Mission CX, carbon, max. 700x40C (with fender) wheelsize
Drivetrain
Rear Derailleur
Shimano CUES U3020, SGS
Shift Levers
Shimano CUES U4000
Cassette
Shimano LG300, 11-36 teeth, 9 speed
Crank
MERIDA COMP TK, 42 teeth, 165mm over all sizes
Bottom Bracket
BSA, 100mm, threaded
Chain
Shimano LG500
Pedals
VP VPE-891
Wheels
Front Hub
Shimano HB-TC500, 100x12mm width front hub, 28 spoke holes, Centerlock
Rear Hub
Shimano HB-TC500, 100x12mm width front hub, 28 spoke holes, Centerlock
Rims
MERIDA COMP SL, 17mm inner width, 22mm height, material: aluminium
Spokes
Black stainless
Tires
Continental Contact Urban, 700Cx40, wire
Brakes
Brakes
Shimano MT200, 2 piston
Cockpit
Handlebar
MERIDA EXPERT CC, material: aluminium, 620mm width, Flat
Headset
MERIDA 8158
Seat
Saddle
MERIDA COMP SL, 28% recycled material, V-mount
Seatpost
MERIDA EXPERT, material: aluminium, 30.9mm diameter, 0mm setback
Motor & Battery
Motor
Mahle X35+, 40Nm
Battery
Mahle B1 248 Wh, integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.511 mm | 1.513 mm | 1.511 mm | 1.51 mm | 1.512 mm |
| Front Center | 611 mm | 623 mm | 634 mm | 645 mm | 654 mm |
| Rake | 45 mm | 46 mm | 45 mm | 45 mm | 45 mm |
| Trail | 82 mm | 78 mm | 76 mm | 73 mm | 69 mm |
| Stack | 565 mm | 581 mm | 597 mm | 613 mm | 629 mm |
| Reach | 374 mm | 384 mm | 395 mm | 406 mm | 416 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 145 mm | 160 mm | 175 mm | 190 mm | 205 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1032 mm | 1044 mm | 1055 mm | 1066 mm | 1076 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 748 mm | 767 mm | 785 mm | 804 mm | 830 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
