Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 40mm -
Fork Suntour XCT
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MATTS J. 20+, material: aluminium, 20x2.4" max. wheelsize, 135x9/100x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Suntour XCT-JR P, Custom coil, 40mm suspension travel, 20x2.2" max. wheelsize
Drivetrain
Rear Derailleur
Shimano RD-M310
Shift Levers
Altus
Cassette
Shimano MF-TZ500, 14-34 teeth, 7 speed
Crank
MERIDA EXPERT JR, 28 teeth, 127 mm
Bottom Bracket
BSA, 100mm, threaded
Chain
KMC NS8
Wheels
Front Hub
Joytech D041DSE, 100x9mm width front hub, 20 spoke holes
Rear Hub
Joytech D242TSE, 135x9mm width rear hub, 24 spoke holes
Rims
MERIDA JR 20+, material: aluminium
Spokes
Black steel
Tires
Kenda Small Black 8, 20x1.95", wire
Brakes
Brakes
Power DS100 / Tektro HD-M275, 2 piston, hydraulic disc brake
Brake Levers
Power DS100
Cockpit
Handlebar
MERIDA EXPERT JR, material: aluminium, 620mm width, 0mm rise
Headset
FSA TH888
Seat
Saddle
MERIDA COMP JR
Seatpost
MERIDA CC, material: aluminium, 27.2mm diameter, 15mm setback
Fit data
Geometry
