Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MATTS J. 20+, material: aluminium, 20x2.4" max. wheelsize, 135x9/100x9mm axle standard, BSA bottom bracket standard
Suspension Fork
MERIDA MATTS J. 20+, material: aluminium, 20x2.4" max. wheelsize
Drivetrain
Rear Derailleur
Shimano RD-TY300
Shift Levers
Shimano SL-M315-7
Cassette
Shimano MF-TZ500, 14-34 teeth, 7 speed
Crank
MERIDA EXPERT JR, 28 teeth, MAT Aluminium, 127 mm
Bottom Bracket
FSA TH-7420ST, 68-124
Chain
KMC Z8.3
Pedals
Marwi SP-202
Wheels
Front Hub
KT-K68F / Joytech D242DSE, 100x9mm width front hub, 20 spoke holes, 135x9mm width rear hub, 24 spoke holes
Rear Hub
KT-K68F / Joytech D242DSE, 100x9mm width front hub, 20 spoke holes, 135x9mm width rear hub, 24 spoke holes
Rims
MERIDA JR 20+, material: aluminium
Spokes
Black steel
Tires
Front: CST Jet C1820, 20x2.4", wire, Rear: CST Jet C1820, 20x2.4", wire
Brakes
Brakes
Tektro M275, hydraulic brake
Cockpit
Stem
MERIDA CC, material: aluminium, 31.8mm diameter, 6? stem angle, 60 mm
Handlebar
MERIDA EXPERT JR, material: aluminium, 620mm width, 25mm rise
Headset
FSA NO.10P Neck15
Seat
Saddle
MERIDA COMP JR
Seatpost
MERIDA COMP CC, 27.2mm diameter, 0mm setback, material: aluminium
Fit data
Geometry
