Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 130mm -
Travel Rear 120mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-TWENTY LITE, 120mm suspension travel, material: aluminium, 29 wheelsize, 148x12mm axle standard, BB92 bottom bracket standard
Suspension Fork
SR Suntour XCR34 LOR, Air, 130mm suspension travel, Tapered, lockout, 51mm fork offset
Rear Shock
SR Suntour Unair TR LOR8, lockout
Drivetrain
Rear Derailleur
Shimano Deore M5100 Shadow+, SGS
Shift Levers
Shimano SL -MT500-L
Cassette
Shimano Deore M5100, 11-51 teeth, 11 speed
Crank
Shimano Deore M5100, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X11
Wheels
Front Hub
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano MT400-B, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP CC, 20mm inner width, material: aluminium
Spokes
Black stainless
Tires
Maxxis Rekon, 29x2.4", wire
Brakes
Brakes
Tektro M275, 2 piston
Cockpit
Handlebar
MERIDA EXPERT CC, material: aluminium, 740mm width, 10mm rise
Headset
FSA NO.47/50
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP TR, 30.9mm diameter, 0mm setback, S: 100mm travel seatpost - M: 125mm travel seatpost - L/XL: 150mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.395 mm | 1.356 mm | 1.354 mm | 1.318 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 701 mm | 729 mm | 725 mm | 753 mm | 776 mm |
| Rake | 42 mm | 51 mm | 42 mm | 52 mm | 50 mm |
| Trail | 107 mm | 101 mm | 107 mm | 100 mm | 102 mm |
| Stack | 581 mm | 607 mm | 590 mm | 616 mm | 626 mm |
| Reach | 415 mm | 435 mm | 435 mm | 455 mm | 475 mm |
| Top Tube Length | 571 mm | 592 mm | 593 mm | 614 mm | 637 mm |
| Seat Tube Angle | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 66.8 ° | 67.3 ° | 66.8 ° | 67.3 ° | 67.3 ° |
| Head Tube Length | 105 mm | 95 mm | 115 mm | 105 mm | 115 mm |
| Chainstay Length | 430 mm | 435 mm | 430 mm | 435 mm | 435 mm |
| Wheelbase | 1130 mm | 1161 mm | 1154 mm | 1185 mm | 1208 mm |
| Bottom Bracket Drop | 21 mm | 40 mm | 21 mm | 40 mm | 40 mm |
| Standover Height | 698 mm | 730 mm | 726 mm | 759 mm | 787 mm |
| Wheels | 27" | 29" | 27" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 189 cm | 199 cm |
