Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REACTO CF4
Suspension Fork
Reacto Carbon superlite-direct
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2
Front Derailleur
Shimano Dura Ace Di2
Shift Levers
Shimano Dura Ace Di2
Cassette
Shimano CS-9000-11 11-28
Crank
Rotor 3D+ Qring 52-38
Chain
Shimano Dura Ace 11s
Wheels
Front Hub
attached
Rear Hub
attached
Rims
Fulcrum Red Wind H50 XLR
Tires
Continental Grand Prix 4000S 23 KV
Brakes
Brakes
Shimano Dura Ace-direct
Brake Levers
attached
Cockpit
Handlebar
FSA K-Force compact OS
Headset
Big Conoid-insert carbon neck CF
Seat
Saddle
Prologo Nago EVO CPC nack
Seatpost
Reacto Aero carbon SL Di2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.38 mm | 1.4 mm | 1.45 mm | 1.48 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm |
| Front Center | 577 mm | 581 mm | 587 mm | 597 mm | 611 mm | 622 mm |
| Rake | 44 mm | 45 mm | 45 mm | 40 mm | 49 mm | 45 mm |
| Trail | 69 mm | 62 mm | 56 mm | 61 mm | 51 mm | 56 mm |
| Stack | 516 mm | 529 mm | 542 mm | 561 mm | 580 mm | 604 mm |
| Reach | 373 mm | 381 mm | 392 mm | 402 mm | 400 mm | 408 mm |
| Top Tube Length | 522 mm | 537 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 109 mm | 124 mm | 139 mm | 159 mm | 184 mm | 209 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 976 mm | 980 mm | 986 mm | 996 mm | 1010 mm | 1021 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 805 mm | 831 mm | 848 mm | 865 mm | 887 mm | 913 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Reacto Team-E-LTD is a Merida E Reacto model. 2 e-bikes variations carry this model name so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Aero e-bikes average price
According to our calculations, the average cost of an Aero e-bike that is reliable is 4258$. However, even though the average price of an Aero e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Overview of components
Fork material
The fork on this e-bike is made out of carbon, so, it won’t add up to much weight to your e-bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on Reacto Team-E-LTD are the 700c carbon type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida Reacto Team-E-LTD is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
