Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RIDE CF4
Suspension Fork
Ride Carbon Superlite flex
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2
Front Derailleur
Shimano Dura Ace Di2
Shift Levers
Shimano Dura Ace Di2
Cassette
Shimano CS-9000-11 11-28
Crank
Rotor 3D30 noQ 50-34
Bottom Bracket
attached
Chain
Shimano Dura Ace 11s
Wheels
Front Hub
attached
Rear Hub
attached
Rims
Fulcrum Racing 1
Tires
Continental Grand Prix 4000S 25 KV
Brakes
Brakes
Shimano Dura Ace
Brake Levers
attached
Cockpit
Handlebar
MERIDA Anatomic Pro OS
Headset
Big Conoid A-bearing neck CF
Seat
Saddle
Prologo Scratch Pro Tirox
Seatpost
FSA K-Force lite SB25 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.43 mm | 1.49 mm | 1.51 mm | 1.56 mm | 1.6 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 576 mm | 583 mm | 584 mm | 589 mm | 599 mm | 615 mm |
| Rake | 32 mm | 48 mm | 48 mm | 46 mm | 48 mm | 56 mm |
| Trail | 80 mm | 60 mm | 57 mm | 56 mm | 53 mm | 42 mm |
| Stack | 583 mm | 539 mm | 560 mm | 578 mm | 600 mm | 626 mm |
| Reach | 368 mm | 378 mm | 377 mm | 383 mm | 384 mm | 391 mm |
| Top Tube Length | 520 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 130 mm | 135 mm | 155 mm | 172 mm | 195 mm | 220 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 978 mm | 985 mm | 986 mm | 994 mm | 1004 mm | 1021 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 793 mm | 816 mm | 835 mm | 835 mm | 874 mm | 903 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Ride Team-E completes the Merida E Ride model. There are 3 e-bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance e-bikes
According to our calculations, the average cost of an Endurance e-bike that is reliable is 3800$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Ride Team-E components
Fork material
When it comes to the fork, this e-bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Merida Ride Team-E 2015, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
