Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RIDE CF5
Suspension Fork
Ride Carbon Superlite flex
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2
Front Derailleur
Shimano Dura Ace Di2
Shift Levers
Shimano Dura Ace Di2
Cassette
Shimano CS-9000-11 11-28
Crank
Rotor 3D30 noQ 52-36 (BB386)
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X11SL DLC
Wheels
Rims
Fulcrum Racing Zero Nite
Tires
Continental Grand Prix 4000S 25 KV
Brakes
Brakes
Shimano Dura Ace
Brake Levers
Shimano Dura Ace
Cockpit
Handlebar
FSA K-Force Compact OS
Headset
FSA No.55 E-CF
Seat
Saddle
Prologo Scratch 2 T2.0
Seatpost
FSA K-Force lite SB25 27.2 [E]
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.43 mm | 1.49 mm | 1.51 mm | 1.56 mm | 1.6 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 576 mm | 583 mm | 584 mm | 589 mm | 599 mm | 615 mm |
| Rake | 32 mm | 48 mm | 48 mm | 46 mm | 48 mm | 56 mm |
| Trail | 80 mm | 60 mm | 57 mm | 56 mm | 53 mm | 42 mm |
| Stack | 583 mm | 539 mm | 560 mm | 578 mm | 600 mm | 626 mm |
| Reach | 368 mm | 378 mm | 377 mm | 383 mm | 384 mm | 391 mm |
| Top Tube Length | 520 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 130 mm | 135 mm | 155 mm | 172 mm | 195 mm | 220 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 978 mm | 985 mm | 986 mm | 994 mm | 1004 mm | 1021 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 793 mm | 816 mm | 835 mm | 835 mm | 874 mm | 903 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
RIDE TEAM-E belongs to the Merida E Ride model. There are 3 e-bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Endurance e-bikes
Our math shows that the average cost of a dependable Endurance e-bike is 3800$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Endurance e-bikes average weight
Endurance e-bikes weigh an average of 13.52 kg (29.81 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
RIDE TEAM-E weighs 6.7 kg (14.77 lbs) and is much lighter than the average. In short, the average Endurance e-bike weight is 101.79% higher than this one.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on RIDE TEAM-E are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida RIDE TEAM-E has Rim brakes installed. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
