Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Force, Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA ENDURANCE CF3 II, material: carbon, 700x35C max./ 700x32C (with fender) max. wheelsize, 100x12/ 142x12mm axle standard, BB86 bottom bracket standard
Suspension Fork
SCULTURA ENDURANCE CF3 DISC, material: carbon, 700x35C max. wheelsize
Drivetrain
Rear Derailleur
SRAM Force AXS
Front Derailleur
SRAM Force AXS
Shift Levers
SRAM Force AXS
Cassette
SRAM XG 1270 D1, 10-36 teeth, 12 speed
Crank
SRAM Force AXS, 46-33 teeth, 165 mm-XXS, 170 mm-XS, 172.5 mm-S/M/L, 175 mm-XL
Bottom Bracket
SRAM Pressfit Dub, Pressfit 86.5
Chain
SRAM Force D1 12S
Wheels
Rims
MERIDA TEAM GR30, 100x12mm width front hub, 142x12mm width rear hub, 25mm inner width, 30mm height, Centerlock, material: carbon
Tires
Continental Terra Speed ProTection, 700x35C, fold
Brakes
Brakes
SRAM Force AXS, Hydraulic disc
Brake Levers
SRAM Force AXS
Cockpit
Handlebar
MERIDA EXPERT GRII, material: aluminium, 380mm (XXS-XS) 400mm (S-M), 420mm (L-XL))
Headset
MERIDA TEAM SL, VP-MRBHB (SE-301 neck)
Seat
Saddle
Prologo Scratch M5 AGX, V-mount adapter, incl. MERIDA minitool
Seatpost
MERIDA TEAM SL, 27.2mm diameter, 15mm setback, Carbon, S-Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.497 mm | 1.508 mm | 1.503 mm | 1.537 mm | 1.55 mm | 1.584 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 583 mm | 588 mm | 592 mm | 592 mm | 608 mm | 617 mm |
| Rake | 49 mm | 48 mm | 48 mm | 48 mm | 49 mm | 47 mm |
| Trail | 68 mm | 66 mm | 60 mm | 53 mm | 52 mm | 51 mm |
| Stack | 539 mm | 552 mm | 565 mm | 584 mm | 603 mm | 629 mm |
| Reach | 360 mm | 366 mm | 376 mm | 380 mm | 389 mm | 397 mm |
| Top Tube Length | 515 mm | 524 mm | 538 mm | 553 mm | 568 mm | 583 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 140 mm | 152 mm | 161 mm | 177 mm | 197 mm | 222 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 992 mm | 997 mm | 1001 mm | 1001 mm | 1017 mm | 1026 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 742 mm | 767 mm | 785 mm | 803 mm | 823 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
