Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Dura-Ace Di2, 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TIME-WARP TRI CF5 IV, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12mm axle standard, Pressfit 86,5
Suspension Fork
TIME-WARP TRI CF5 IV disc, material: carbon, 700x30C max. wheelsize
Drivetrain
Rear Derailleur
Shimano 105 Di2
Front Derailleur
Shimano 105 Di2
Shift Levers
Shimano ST-R9160
Cassette
Shimano 105 R7101, 11-34 teeth, 12 speed
Crank
Shimano 105, 52-36 teeth, 170 mm-XS, 172.5 mm-S/M, 175 mm-L
Bottom Bracket
BB86/BB92, 86mm, press-fit
Chain
Shimano M6100-12
Wheels
Front Hub
Shimano HB-TC500, 100x12mm width front hub, 28 spoke holes, Centerlock
Rear Hub
Shimano HB-TC500-HL, 12-142mm width rear hub, 28 spoke holes, Centerlock
Rims
MERIDA EXPERT CW, 19mm inner width, 30mm height, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Maxxis Highroad, 700x28C, fold, tubeless ready
Brakes
Brakes
Riverever Triva, Hydraulic disc
Cockpit
Handlebar
MERIDA Metron TT, material: carbon
Headset
MERIDA TIME WARP TT
Seat
Saddle
MERIDA EXPERT SL, 6% recycled and 23% nature material, V-mount, incl. MERIDA minitool
Seatpost
MERIDA TEAM TT II, Aero shape, Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.319 mm | 1.36 mm | 1.278 mm | 1.344 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 266 mm | 266 mm |
| Front Center | 575 mm | 579 mm | 617 mm | 640 mm |
| Rake | 42 mm | 43 mm | 43 mm | 43 mm |
| Trail | 71 mm | 64 mm | 64 mm | 64 mm |
| Stack | 496 mm | 518 mm | 533 mm | 574 mm |
| Reach | 376 mm | 381 mm | 417 mm | 427 mm |
| Top Tube Length | 490 mm | 510 mm | 550 mm | 570 mm |
| Seat Tube Angle | 77 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 130 mm | 130 mm | 173 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 984 mm | 988 mm | 1022 mm | 1045 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 781 mm | 799 mm | 838 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
