Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano 105 Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Adrenaline - G2 Carbon Concept Lite Frame. Intermediate Carbon Fiber. Monocoque. Fully Internal Cable Routing. Flat Mount. E+ Compatible. PressFit. Headtube 1.5
Suspension Fork
Adrenaline - G2 Carbon Concept Lite Fork. TA 12mm
Drivetrain
Rear Derailleur
Shimano 105 Di2 R7150 12V
Cassette
Shimano 105 R7100 11-34 12V
Crank
Shimano 105 R7100 50-34 12V
Chain
Shimano M6100
Wheels
Rims
DT Swiss A1800 30
Tires
Hutchinson Blackbird 28 TLR
Brakes
Brakes
Shimano 105 R7170
Cockpit
Stem
FSA SMR II
Handlebar
FSA Energy
Seat
Saddle
Selle Italia Model Epsilon
Seatpost
FSA Energy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.354 mm | 1.388 mm | 1.411 mm | 1.433 mm | 1.459 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 572 mm | 580 mm | 590 mm | 600 mm | 612 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 68 mm | 62 mm | 59 mm | 55 mm | 52 mm |
| Stack | 501 mm | 526 mm | 546 mm | 566 mm | 591 mm |
| Reach | 370 mm | 379 mm | 387 mm | 395 mm | 405 mm |
| Top Tube Length | 509 mm | 530 mm | 549 mm | 568 mm | 591 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 490 mm | 530 mm | 560 mm | 600 mm |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° | 73 ° | 73.5 ° |
| Head Tube Length | 102 mm | 125 mm | 144 mm | 163 mm | 187 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 972 mm | 980 mm | 990 mm | 1000 mm | 1012 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
