Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Ultegra, Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano Ultegra Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Adrenaline Aero - G3 Carbon Concept Lite Frame. Intermediate Modulus Carbon Fiber. Monocoque. TA 12mm. Fully Internal Cable Routing. Flat Mount. E+ Compatible. PressFit. Headtube 1.5
Suspension Fork
Adrenaline Aero - G3 Carbon Concept Lite Fork. TA 12mm
Drivetrain
Rear Derailleur
Shimano Ultegra Di2 R8150 12V
Cassette
Shimano Ultegra R8100 11-34T 12V
Crank
Shimano Ultegra R8100 50-34T 12V
Chain
Shimano M6100
Wheels
Rims
VISION SC45
Tires
Hutchinson Blackbird 28 TLR
Brakes
Brakes
Shimano Ultegra Di2 R8170
Cockpit
Handlebar
Vision Metron 5D EVO
Seat
Saddle
Selle Italia SLR Boost Superflow
Seatpost
MMR Aero Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.325 mm | 1.37 mm | 1.386 mm | 1.376 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 577 mm | 580 mm | 594 mm | 610 mm | 627 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 61 mm | 58 mm | 58 mm | 58 mm |
| Stack | 500 mm | 514 mm | 544 mm | 564 mm | 578 mm |
| Reach | 376 mm | 388 mm | 397 mm | 407 mm | 420 mm |
| Top Tube Length | 520 mm | 535 mm | 553 mm | 569 mm | 585 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 460 mm | 500 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 115 mm | 145 mm | 165 mm | 180 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 974 mm | 977 mm | 991 mm | 1007 mm | 1024 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
