Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Motor MAHLE 250W hub-drive -
Battery MAHLE EbikeMotion 250 wh. Integrada. -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Beat- G1. AC Frame. Aluminium 6061. Hydroformed doble butted. Internal Cable Routing. Flat Mount. Full integrated battery. Press Fit. Headtube tapered 1.5
Suspension Fork
Beat - G1 Carbon Concept Lite Fork. TA 12 mm
Drivetrain
Shift Levers
Shimano 105 R7000 11v
Cassette
Shimano 105 R7000 11-30
Crank
Shimano RS510 34x50
Chain
Shimano HG-601
Wheels
Rims
XCR 7400 DW Aluminium TL
Tires
Hutchinson Sector 32c
Brakes
Brakes
Shimano 105 160/160
Cockpit
Stem
Ritchey Comp 4 Axis
Handlebar
Ritchey Comp curve
Headset
Ritchey Pro Integrada Tapered 1.5
Seat
Saddle
Selle Italia X3 Boost
Seatpost
Ritchey Logic 27.2 mm
Motor & Battery
Motor
MAHLE EbikeMotion 250 w
Battery
MAHLE EbikeMotion 250 wh. Integrada.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.5 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 562 mm | 586 mm | 603 mm | 621 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 68 mm | 63 mm | 63 mm | 63 mm |
| Stack | 525 mm | 549 mm | 571 mm | 596 mm |
| Reach | 355 mm | 366 mm | 376 mm | 386 mm |
| Top Tube Length | 504 mm | 531 mm | 553 mm | 571 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 510 mm | 540 mm | 560 mm | 600 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 130 mm | 155 mm | 180 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 974 mm | 998 mm | 1015 mm | 1033 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
BEAT 00 is part of the Mmr E Beat model. MMR launched 2 e-bikes of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Endurance e-bikes
If you want an acceptable Endurance e-bike you should know that the average price is 3800$. However, you could also get a good Endurance e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2021 for 2824$. Comparing the average cost of an Endurance e-bike to this one, you will see that BEAT 00 price is 34.56% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
BEAT 00 components
Fork material
The fork on this e-bike is made out of carbon, so, it won’t add up to much weight to your e-bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on BEAT 00 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
BEAT 00 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
