Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork XCR -
Groupset SX Eagle -
Suspension Hardtail -
Motor MAHLE hub-drive -
Battery Ex1 Mahle -
Drivetrain 1 × 12 -
Brakes SRAM Level Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-Woki - G1 Alloy Concept Frame. Aluminum 6061. Hydroformed Double Butter. QR. Optimized Cable Routing. Post Mount
Suspension Fork
XCR 29
Drivetrain
Rear Derailleur
SRAM SX 12V
Cassette
SRAM SX 11-50 12V
Crank
SRAM SX
Chain
SRAM SX
Wheels
Rims
XCR 30 Alloy 29'' MAHLE X30 TLR
Tires
Hutchinson Republic TUBETYPE 700X50
Brakes
Brakes
SRAM Level
Cockpit
Stem
XCR Alloy
Handlebar
XCR Alloy
Headset
Ritchey Logic
Seat
Saddle
Selle Italia Model X
Seatpost
XCR Alloy 27.2
Motor & Battery
Motor
X30 Mahle
Battery
Ex1 Mahle
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.601 mm | 1.6 mm | 1.598 mm | 1.58 mm |
| Front Center | 638 mm | 652 mm | 652 mm | 677 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 75.5 mm | 75.5 mm | 75.5 mm | 75.5 mm |
| Stack | 610 mm | 624 mm | 633 mm | 643 mm |
| Reach | 381 mm | 390 mm | 396 mm | 407 mm |
| Top Tube Length | 560 mm | 575 mm | 590 mm | 605 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 395 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1077 mm | 1090 mm | 1090 mm | 1115 mm |
| Bottom Bracket Drop | 55 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
