Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Grip- G2 AC Concept Frame. Aluminum 6061. Hydroformed Triple Butted. TA 12mm. Optimized cable routing. Flat Mount. Headtube tapered 1.5mm
Suspension Fork
Grip - G2 Carbon Concept Fork. TA 12mm
Drivetrain
Rear Derailleur
Shimano Sora R3000 9V
Cassette
Shimano HG-40 11-32 9V
Crank
Shimano Sora R3000 34x50
Chain
Shimano HG-53 9V
Wheels
Rims
XCR 7400 SLR
Tires
Hutchinson Nitro-2 700x28
Brakes
Brakes
Shimano RS-305 160/160
Cockpit
Stem
Ritchey Comp Switch
Handlebar
Ritchey Comp Curve
Headset
Ritchey Comp Integrated Tapered 1.5
Seat
Saddle
Selle Italia Model
Seatpost
Ritchey Comp 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.317 mm | 1.4 mm | 1.449 mm | 1.487 mm | 1.523 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 574 mm | 581 mm | 593 mm | 604 mm | 623 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 68 mm | 65 mm | 59 mm | 59 mm | 59 mm |
| Stack | 494 mm | 525 mm | 555 mm | 580 mm | 609 mm |
| Reach | 375 mm | 375 mm | 383 mm | 390 mm | 400 mm |
| Top Tube Length | 507 mm | 525 mm | 547 mm | 568 mm | 586 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 490 mm | 530 mm | 560 mm | 600 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 95 mm | 125 mm | 153 mm | 180 mm | 210 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 976 mm | 983 mm | 995 mm | 1006 mm | 1025 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
