Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 110mm -
Fork RockShox SID SL Ultimate
-
Groupset GX Eagle Transmission -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Shimano XT Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kenta; Mid Modulus Carbon Fiber; 29x2.4" max; 148x12; Pressfit 92
Suspension Fork
Rock Shox Sid SL Ultimate 110
Rear Shock
Rock Shox SidLuxe Ultimate 190x40; HW-30/22.2
Drivetrain
Rear Derailleur
SRAM GX Eagle Transmission AXS
Cassette
SRAM XS 1275 10-52
Crank
SRAM GX Eagle 34
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM GX Eagle Transmission Flattop Chain
Wheels
Rims
FSA SC i30 TLR Carbon
Tires
Hutchinson Python 3 Racing Line TR; 29x2.30
Brakes
Brakes
Shimano XT M8200
Cockpit
Stem
FSA NS SIC INTEGRATED S/M= 60mm L= 80mm
Handlebar
FSA NS SIC INTEGRATED 760MM
Headset
FSA NO.69 SRS
Seat
Saddle
San Marco Shortfit
Seatpost
OneUp V3 120mm dropper post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.388 mm | 1.333 mm | 1.295 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm |
| Front Center | 703 mm | 732 mm | 764 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm |
| Stack | 590 mm | 600 mm | 615 mm |
| Reach | 425 mm | 450 mm | 475 mm |
| Top Tube Length | 571 mm | 598 mm | 627 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 430 mm | 457 mm | 508 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 85 mm | 96 mm | 112 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1135 mm | 1164 mm | 1196 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
