Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork Fox
-
Groupset X0 Eagle Transmission -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kenta- G3 Carbon Concept Lite Frame. High Modulus carbon fiber. Monocoque. TA 12mm. Internal Cable Routing. Boost. PostMount. Flexion 4 pivot. E+ Compatible. PressFit. Head tube Tapered 1.5.
Suspension Fork
Fox Performance 15 Boost. Travel 100mm. Remote Lockout. Tapered.
Rear Shock
Fox Performance Elite Float DPS Remote Lockout.
Drivetrain
Rear Derailleur
SRAM X0 AXS T-TYPE
Cassette
SRAM T-TYPE 12V 10-52
Crank
SRAM X0 T-TYPE 34T
Chain
SRAM X0 Eagle T-TYPE
Wheels
Rims
DT X-1900 MS TLR
Tires
Hutchinson Kraken TLR 29x2.30
Brakes
Brakes
Shimano XT M8100 180/160
Cockpit
Stem
Ritchey Comp 4 Axis
Handlebar
Ritchey Comp 2X Dual Position 9º Sweep 720 mm
Grips
Ritchey WCS Evergrip Silicone
Headset
Ritchey Pro Integrated 1.5
Seat
Saddle
San Marco Shortfit Supercomfort Dynamic Wide
Seatpost
Race Face Aeffect R 125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.417 mm | 1.368 mm | 1.325 mm |
| Bottom Bracket Height | 324 mm | 324 mm | 324 mm |
| Front Center | 678 mm | 708 mm | 739 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 89 mm | 89 mm | 89 mm |
| Stack | 588 mm | 602 mm | 616 mm |
| Reach | 415 mm | 440 mm | 465 mm |
| Top Tube Length | 562 mm | 590 mm | 618 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 430 mm | 457 mm | 509 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1108 mm | 1138 mm | 1169 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
