Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Fork RockShox SID
-
Groupset GX Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kenta- G3 Carbon Concept Lite Frame. High Modulus carbon fiber. Monocoque. TA 12mm. Internal Cable Routing. Boost. PostMount. Flexion 4 pivot. E+ Compatible. PressFit. Head tube Tapered 1.5.
Suspension Fork
RockShox SID Base 35 RL 15 Boost. Fast black. Travel 120mm. Motion Control. One Lock Remote. Tapered.
Rear Shock
RockShox SID Luxe Ultimate RLR
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS 12V
Cassette
SRAM GX Eagle XG-1275 12V 10-52
Crank
SRAM GX Eagle Boost DUB 34
Chain
SRAM GX Eagle 12V
Wheels
Rims
DT Swiss X1900
Tires
Hutchinson Kraken TLR 29x2.30
Brakes
Brakes
Shimano MT-501 180/160
Cockpit
Stem
Race Face Ride 35
Handlebar
Race Face Ride 35 760mm
Grips
Rock Shox Twistloc Base Fullsprint
Headset
Ritchey Pro Integrated Tapered 1.5
Seat
Saddle
San Marco Shortfit Supercomfort Dynamic Wide
Seatpost
Rock Shox Reverb Dropper 125mm 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.469 mm | 1.416 mm | 1.369 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm |
| Front Center | 684 mm | 714 mm | 744 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 95 mm | 95 mm |
| Stack | 595 mm | 609 mm | 623 mm |
| Reach | 405 mm | 430 mm | 455 mm |
| Top Tube Length | 562 mm | 590 mm | 618 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 430 mm | 457 mm | 509 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1116 mm | 1146 mm | 1176 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
