Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Motor MAHLE 250W hub-drive -
Battery MAHLE Ebike Motion 250Wh. Integrated -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Beat - G1. AC Frame. Aluminum 6061. Hydroformed double butted. Internal Cable Routing. Flat Mount. Full Integrated Battery. PressFit. Headtube tapered 1.5
Suspension Fork
X-Beat- G1 Carbon Concept Lite Fork. TA 12mm
Drivetrain
Rear Derailleur
Shimano GRX RX812 11V
Cassette
Shimano SLX M7000 11V 11-42
Crank
Shimano GRX RX600 40
Chain
Shimano HG-601 11V
Wheels
Rims
XCR 7400 Hybrid DW Alloy 6063 MS
Tires
Hutchinson Overide 700x38
Brakes
Brakes
Shimano GRX RX810 160/160
Cockpit
Stem
Ritchey Comp 4 Axis
Handlebar
Ritchey Comp Road Curve
Headset
Ritchey Comp Integrated Tapered 1.5
Seat
Saddle
Selle Italia X3 Boost
Seatpost
Ritchey Logic 27.2
Motor & Battery
Motor
MAHLE Ebike Motion X35 250w
Battery
MAHLE Ebike Motion 250Wh. Integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.5 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 562 mm | 586 mm | 603 mm | 621 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 71 mm | 66 mm | 66 mm | 66 mm |
| Stack | 525 mm | 549 mm | 571 mm | 596 mm |
| Reach | 355 mm | 366 mm | 376 mm | 386 mm |
| Top Tube Length | 504 mm | 531 mm | 553 mm | 571 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 510 mm | 540 mm | 560 mm | 600 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 130 mm | 155 mm | 180 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 974 mm | 998 mm | 1015 mm | 1033 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
X-Beat belongs to the Mmr E X Beat model. There are 3 e-bikes that carry this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel e-bikes average price
According to our calculations, the average cost of a Gravel e-bike that is reliable is 3642$. However, even though the average price of a Gravel e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
At the moment of the release date, MMR X-Beat price was 3026$. Doing a quick comparison, we notice that X-Beat price is 20.36% lower than the average cost of a Gravel e-bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
X-Beat has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The X-Beat 2023 e-bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
