Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Grip - G1 AC Concept Frame. Aluminium 6061. Hydroformed Triple Butted. TA 12mm. Optimized Cable Routing. Flat Mount. Headtube tapered 1.5 mm
Suspension Fork
X-Grip - G1 Carbon Concept Fork. TA 12mm
Drivetrain
Shift Levers
Shimano GRX 810 11V
Cassette
Shimano 105 R7000 11-34 11V
Crank
Shimano GRX 600 36X46
Chain
Shimano HG-601 11V
Wheels
Rims
Shimano RS-171
Tires
Hutchinson Overide 700x38
Brakes
Brakes
Shimano GRX 600 160/160
Cockpit
Stem
Ritchey Comp Switch
Handlebar
Ritchey Comp Curve
Headset
Ritchey Comp Integrada Tapered 1.5
Seat
Saddle
Selle Italia X3 Boost Flow
Seatpost
Ritchey Logic 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.5 mm | 1.52 mm | 1.56 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 578 mm | 587 mm | 605 mm | 627 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 74 mm | 68 mm | 68 mm | 68 mm |
| Stack | 543 mm | 570 mm | 594 mm | 627 mm |
| Reach | 370 mm | 380 mm | 390 mm | 401 mm |
| Top Tube Length | 524 mm | 547 mm | 570 mm | 591 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 600 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1003 mm | 1012 mm | 1030 mm | 1052 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
X-GRIP 00 completes the Mmr X Grip model. MMR released 4 bikes variations of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1858$. Comparing the average cost of a Gravel bike to this one, you will see that X-GRIP 00 price is 32.51% lower.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the X-GRIP 00 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
