Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore -
Suspension Rigid -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum 26" fat bike geometry internal cable routing 9 mm x 190 mm QR axle replaceable hanger tapered headtube
Suspension Fork
Mongoose aluminum ridged fork 26" aluminum steerer 9 mm x 135 mm QR axle
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000
Shift Levers
Shimano SL-610 10
Crank
Prowheel Charm 28T
Bottom Bracket
Prowheel 2-piece 100 mm shell
Pedals
Mongoose nylon
Wheels
Front Hub
Xposure aluminum ball bearing 9 mm x 135 mm 32H 6-bolt rotor
Rear Hub
Tektro HD-M290 hydraulic aluminum 180 mm rotor
Rims
Mongoose aluminum single wall 95 mm ID 32H
Spokes
14G, stainless steel
Tires
Xposure 26 in x 4.8 in folding bead
Brakes
Brakes
Tektro HD-M290 hydraulic aluminum 180 mm rotor
Brake Levers
Tektro M290
Cockpit
Stem
Xposure 3D forged aluminum threadless 60 mm 6° 35 mm clamp
Grips
Xposure Kraton semi-ergo
Headset
Threadless ZS44/ZS56 retainer bearing
Seat
Saddle
Mongoose MTB steel rails
Seatpost
Xposure aluminum 350 mm zero offset 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.621 mm | 1.618 mm |
| Bottom Bracket Height | 283 mm | 283 mm |
| Front Center | 675 mm | 694 mm |
| Rake | 51 mm | 51 mm |
| Trail | 71 mm | 71 mm |
| Stack | 652.4 mm | 671.2 mm |
| Reach | 402.5 mm | 414.8 mm |
| Top Tube Length | 602 mm | 620 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 70 ° | 70 ° |
| Head Tube Length | 135 mm | 155 mm |
| Chainstay Length | 460 mm | 460 mm |
| Wheelbase | 1128 mm | 1147 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Standover Height | 803 mm | 843 mm |
| Wheels | 26" | 26" |
