Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Shimano -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tectonic T1, aluminum, 20" urban geometry, horizontal dropout
Suspension Fork
Aluminum rigid fork, 20", aluminum steerer, aluminum blades, 9 mm x 100 mm, QR
Drivetrain
Shift Levers
Shimano SL-3S41, 3
Crank
Prowheel PRA-112PP, aluminum, 32T
Bottom Bracket
Prowheel, cartridge, 3-piece, threaded 68 mm shell
Chain
KMC Z1 Wide
Pedals
Mongoose, nylon
Wheels
Front Hub
Xposure, aluminum, ball bearing, 9 mm x 100 mm, 24H
Rear Hub
Shimano Nexus 3-speed internally geared hub
Rims
Xposure XP-163, aluminum single wall, 20 mm ID, 24H, non tubeless
Spokes
14G, stainless steel
Tires
Kenda K-1153, 20 in x 1.75 in, wire bead
Brakes
Brakes
Mongoose, V-brake, aluminum
Cockpit
Stem
Xposure, threadless, 60 mm, 25.4 mm clamp
Handlebar
Xposure, aluminum, 520mm width, 25.4 mm clamp
Grips
Xposure, single density
Headset
Threadless, retainer bearing
Seat
Saddle
Mongoose kids, steel rails
Seatpost
Xposure, aluminum, 300 mm, zero offset, 27.2 mm
Fit data
Geometry
