Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 80mm -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, 27.5" trail geometry, 10 mm x 135 mm dropout, replaceable hanger, tapered headtube
Suspension Fork
Mongoose, 27.5", 100 mm, QR, 80 mm travel
Drivetrain
Rear Derailleur
L-Twoo
Shift Levers
L-Twoo, 7x7
Crank
Mongoose, aluminum, 30T
Bottom Bracket
Square taper
Chain
KMC Z7
Pedals
Mongoose, nylon
Wheels
Front Hub
Steel, 100 mm QR, 32H, 6-bolt
Rear Hub
Steel, 135 mm bolt-on, 32H, 6-bolt
Rims
Aluminum, double wall, 32H
Spokes
14G, steel, black
Tires
27.5 in x 2.6 in, wire bead
Brakes
Brakes
Mongoose, mechanical disc, aluminum, 160 mm
Cockpit
Stem
Aluminum, threadless, 40 mm, 31.8 mm clamp
Handlebar
Steel, 720 mm width, 15 mm rise, 31.8 mm clamp
Grips
Mongoose, Kraton
Headset
Threadless, ZS44 / ZS56
Seat
Saddle
Mongoose MTB, steel rails
Seatpost
Steel, 300 mm, 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.328 mm | 1.268 mm |
| Bottom Bracket Height | 305 mm | 305 mm |
| Front Center | 733 mm | 765 mm |
| Rake | 51 mm | 51 mm |
| Trail | 99 mm | 99 mm |
| Stack | 587 mm | 596 mm |
| Reach | 442 mm | 470 mm |
| Top Tube Length | 610 mm | 641 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 450 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm |
| Wheelbase | 1163 mm | 1195 mm |
| Bottom Bracket Drop | 50 mm | 50 mm |
| Standover Height | 696 mm | 709 mm |
| Wheels | 27" | 27" |
