Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Groupset Tourney, Altus -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum 26" cargo geometry, internal cable routing, 9 mm x 141 mm dropout, replaceable hanger,
Suspension Fork
Mongoose 26" Hi-Ten steel 9 mm x 100 mm QR
Drivetrain
Rear Derailleur
Shimano Altus RD-M310
Front Derailleur
Shimano FD-TX800
Shift Levers
Shimano EF500
Crank
Prowheel 42/32/22T
Bottom Bracket
VP cartridge 3-piece threaded 73mm BB shell
Chain
KMC Z72
Pedals
Mongoose nylon
Wheels
Front Hub
Xposure aluminum ball bearing 9 mm x 100mm 32H 6-bolt
Rear Hub
Xposure, aluminum, ball bearing, 9 mm x 141 mm, 32H, 6-bolt
Rims
Xposure aluminum double wall 26 mm ID, 32H
Spokes
14G stainless steel
Tires
Xposure 26" x 2.35"
Brakes
Brakes
Mongoose mechanical, aluminum, 180mm (F) 160mm (R)
Brake Levers
Shimano BR-EF505
Cockpit
Stem
Xposure aluminum, quill, 70 mm, 7°, 25.4 mm clamp
Handlebar
Xposure, aluminum, 710 mm width, 0 mm rise, 25.4 mm clamp
Grips
Xposure Kraton, semi-ergo
Headset
threadless ZS44/ZS44 retainer bearing
Seat
Saddle
Mongoose MTB comfort steel
Seatpost
Xposure, aluminum, 400 mm, 20 mm offset, 27.2mm seat post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | MD/LG |
|---|---|---|
| Stack Reach Ratio | 1.272 mm | 1.222 mm |
| Front Center | 641 mm | 680 mm |
| Rake | 45 mm | 45 mm |
| Trail | 49 mm | 49 mm |
| Stack | 524 mm | 544 mm |
| Reach | 412 mm | 445 mm |
| Top Tube Length | 586 mm | 625 mm |
| Seat Tube Angle | 72.8 ° | 72.8 ° |
| Seat Tube Length | 432 mm | 500 mm |
| Head Tube Angle | 71 ° | 71 ° |
| Head Tube Length | 160 mm | 180 mm |
| Chainstay Length | 640 mm | 640 mm |
| Wheelbase | 1279 mm | 1318 mm |
| Bottom Bracket Drop | 38 mm | 38 mm |
| Standover Height | 744 mm | 790 mm |
| Wheels | 26" | 26" |
