Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork RST DIRT
-
Groupset Altus -
Suspension Hardtail -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tectonic T1, 6061 aluminum, 26" dirt jump geometry, 9 mm x 135 mm dropout, replaceable hanger
Suspension Fork
RST DIRT-T, 26", aluminum steerer, 9 mm x 100 mm, thru axle, 100 mm travel
Drivetrain
Rear Derailleur
Shimano Altus RD-M2000
Shift Levers
Shimano Altus SL-2000, 9
Crank
Samox AF15-D36S, aluminum, 36T
Bottom Bracket
Samox, cartridge, 3-piece, threaded 68 mm shell
Chain
KMC Z99
Pedals
Mongoose, nylon
Wheels
Front Hub
Xposure, aluminum, ball bearing
Rear Hub
Xposure, aluminum, ball bearing, 9 mm x 135 mm, 32H, 6-bolt
Rims
Aluminum double wall, 26 mm ID, 32H
Spokes
14G, steel
Tires
Kenda Small Block, 26 in x 2.35 in, wire bead
Brakes
Brakes
Mongoose, mechanical, aluminum, 160 mm rotor
Cockpit
Stem
Xposure melt forged aluminum, threadless, 40 mm, 7? 31.8 mm clamp
Handlebar
Xposure double-butted, aluminum, 750 mm width, 30 mm rise, 31.8 mm clamp
Grips
Mongoose Hive, single density
Headset
Threadless, ZS44 / ZS56 with reducer, retainer bearing
Seat
Saddle
Mongoose Dirt jump, integrated rails
Seatpost
Xposure, aluminum, 201 mm, integrated saddle, 27.2 mm
Fit data
Geometry
