Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Manitou Circus Expert
-
Suspension Hardtail -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tectonic T1, 6061 aluminum, 26" dirt jump geometry, 9 mm x 135 mm dropout, replaceable hanger
Suspension Fork
Manitou Circus Expert, 26", aluminum steerer, 20 mm x 110 mm, thru axle, 100 mm travel
Drivetrain
Crank
Samox CW-1448M, aluminum, 25T
Bottom Bracket
Samox, Euro cartridge bearing, 8-spline axle, threaded 68 mm shell
Chain
KMC Z510
Pedals
Mongoose, aluminum
Wheels
Front Hub
Xposure, aluminum, sealed-bearing, 9 mm x 110 mm, 32H, 6-bolt
Rear Hub
Xposure, aluminum, sealed-bearing, 3/8" x 135 mm, 32H, 6-bolt
Rims
Xposure, aluminum double wall, 26 mm ID, 32H
Spokes
14G, steel
Tires
Kenda Small Block, 26 in x 2.35 in, wire bead
Brakes
Brakes
Mongoose, front mechanical, rear hydraulic, aluminum, 160 mm rotor
Cockpit
Stem
Promax DA-269, aluminum, threadless, 40 mm, 7°, 31.8 mm clamp
Handlebar
Xposure double-butted, aluminum, 750 mm width, 30 mm rise, 31.8 mm clamp
Grips
Mongoose Hive, single density
Headset
Threadless, ZS44/ZS56 with reducer, retainer bearing
Seat
Saddle
Mongoose Dirt jump, integrated rails
Seatpost
Xposure, aluminum, 200 mm, integrated saddle, 27.2 mm
Fit data
Geometry
