Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCR
-
Groupset Apex -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes SRAM Apex Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tectonic T2, aluminum, 700c adventure geometry, Top Tube braze ons, internal cable routing, 9 mm x 141 mm QR dropout convertible to 12 mm x 148 mm thru axle, replaceable hanger, tapered headtube
Suspension Fork
SR Suntour XCR32- Coil LO, 29", aluminum steerer, 9 mm x 100 mm, QR, 100 mm travel
Drivetrain
Rear Derailleur
SRAM Apex
Shift Levers
SRAM Apex, 11-speed
Crank
Prowheel Charm, aluminum, 30T
Bottom Bracket
Prowheel, cartridge, 3-piece, threaded 73 mm shell
Chain
KMC X11
Pedals
Mongoose, nylon
Wheels
Front Hub
Xposure, aluminum, ball bearing, 9 mm x 100 mm, 32H, 6-bolt
Rear Hub
Xposure, aluminum, ball bearing, 9 mm x 141 mm, 32H, 6-bolt
Rims
WTB ST-i29, aluminum double wall, 29 mm ID, 32H, tubeless compatible,
Spokes
14G, stainless steel
Tires
Kenda Karma, 29 in x 2.20 in, wire bead
Brakes
Brakes
SRAM Apex post mount, hydraulic, aluminum, 160 mm rotor
Cockpit
Stem
Xposure 3D forged aluminum, threadless, 60 mm, -17°, 31.8 mm clamp
Handlebar
Xposure, aluminum, 380 mm - 440 mm width, 25 deg flare rise, 31.8 mm clamp
Grips
Xposure, non-slip tape
Headset
Threadless, ZS44/ZS56, retainer bearing
Seat
Saddle
Mongoose adventure, steel rails
Seatpost
Xposure, aluminum, 350 mm, zero offset, 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.712 mm | 1.717 mm | 1.736 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm |
| Front Center | 624 mm | 646 mm | 663 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 92 mm | 92 mm | 93 mm |
| Stack | 625 mm | 649 mm | 672 mm |
| Reach | 365 mm | 378 mm | 387 mm |
| Top Tube Length | 545 mm | 565 mm | 580 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406 mm | 480 mm | 530 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 90 mm | 115 mm | 140 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1060 mm | 1082 mm | 1099 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 758 mm | 813 mm | 852 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
