Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes JAK Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, internal cable routing, replaceable hanger, tapered headtube
Suspension Fork
Element, 100 mm travel
Drivetrain
Rear Derailleur
Pro Rush
Shift Levers
Pro Rush, 7-speed
Crank
Aluminum, 30T
Bottom Bracket
Semi-cartridge, square taper, 68 mm
Chain
KMC Z7
Pedals
Mongoose, nylon
Wheels
Front Hub
Steel, 32H, 6-bolt
Rear Hub
Steel, 32H, 6-bolt
Rims
Aluminum, double wall, 32H
Spokes
14G, steel, black
Tires
27.5 in x 2.6 in, wire bead
Brakes
Brakes
JAK 7, mechanical disc, aluminum, 160 mm rotor
Cockpit
Stem
Aluminum, threadless, 40 mm, 7? rise, 31.8 mm clamp
Handlebar
Mongoose, steel, 720 mm width, 15 mm rise, 31.8 mm clamp
Grips
Mongoose, Kraton
Headset
Threadless, ZS44 / ZS56 w/reducer, loose ball bearing
Seat
Saddle
Mongoose MTB, steel rails
Seatpost
Aluminum, 350 mm, 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 27.5" wheel |
|---|---|
| Stack Reach Ratio | 1.281 mm |
| Bottom Bracket Height | 320 mm |
| Front Center | 747 mm |
| Rake | 51 mm |
| Trail | 104 mm |
| Stack | 608.4 mm |
| Reach | 475.1 mm |
| Top Tube Length | 610 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 430 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 110 mm |
| Chainstay Length | 450 mm |
| Wheelbase | 1195 mm |
| Bottom Bracket Drop | 35 mm |
| Standover Height | 718 mm |
| Wheels | 27" |
