Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tectonic T1 6061 aluminum, 26" fat bike geometry, 9 mm x 190 mm QR axle, replaceable hanger, 1 1/8 in headtube
Suspension Fork
Aluminum rigid fork 26" aluminum steerer, 9 mm x 135 mm QR axl
Drivetrain
Rear Derailleur
Shimano RD-TX800
Front Derailleur
MicroSHIFT FD-M462D, 34.9 mm clamp
Shift Levers
Shimano SL-M315, 2 x 8
Crank
Prowheel TM-CY10 36/22T
Bottom Bracket
Square taper, 120 mm
Chain
KMC Z8.1
Pedals
Nylon
Wheels
Front Hub
Aluminum ball bearing 9 mm x 135 mm 36H 6-bolt
Rear Hub
Aluminum ball bearing 10 mm x 190 mm QR 36H 6-bolt
Rims
Xposure aluminum 95 mm ID 36H
Spokes
14G, steel, black
Tires
Xposure 26 in x 4.0 in wire bead
Brakes
Brakes
Mechanical disc, aluminum, 180 mm front, 160 mm rear rotor
Brake Levers
Aluminum
Cockpit
Stem
Aluminum threadless 90 mm 7° rise 31.8 mm clamp 31.8 mm clamp
Handlebar
Xposure aluminum 700 mm 25 mm 31.8 mm clamp
Grips
Xposure Kraton
Headset
Threadless ZS44 retainer bearing
Seat
Saddle
Steel railed
Seatpost
Aluminum 300 mm 31.6 mm
