Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 80mm -
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tectonic T1, aluminum, 27.5" sport geometry, internal cable routing, 9 mm x 135 mm dropout, replaceable hanger
Suspension Fork
Xposure, 27.5", steel steerer, lockout, 9 mm x 100 mm, QR, 80 mm travel
Drivetrain
Rear Derailleur
Shimano Altus RD-M370
Front Derailleur
Shimano FD-2020, band clamp
Shift Levers
Shimano SL-M2000, 2 x 9
Crank
Shimano MT-101-2, aluminum, 36/22T
Bottom Bracket
Feimin FP-B609W, cartridge, 3-piece, threaded 73 mm shell
Chain
KMC Z9
Pedals
Mongoose, nylon
Wheels
Front Hub
Xposure, aluminum, ball bearing, 9 mm x 100 mm, 32H, 6-bolt
Rear Hub
Xposure, aluminum, ball bearing, 9 mm x 135 mm, 32H, 6-bolt
Rims
Xposure MD-16, aluminum double wall, 19 mm ID, 32H
Spokes
14G, stainless steel
Tires
Kenda MTB, 27.5 in x 2.1 in, wire bead
Brakes
Brakes
Tektro aluminum mechanical disc, 160 mm rotor, mechanical, aluminum, 160 mm rotor
Cockpit
Stem
Xposure diecast, threadless, 70 mm/90 mm, 7°, 31.8 mm clamp
Handlebar
Xposure, double-butted aluminum, 700 mm width, 25 mm rise, 31.8 mm clamp
Grips
Xposure Kraton, single density
Headset
Threadless, ZS44/ZS44, retainer bearing
Seat
Saddle
Mongoose MTB comfort, steel rails
Seatpost
Xposure, aluminum, 27.2 mm with 20 mm offseat
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.956 mm | 2.011 mm | 1.528 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm |
| Front Center | 621 mm | 639 mm | 655 mm |
| Rake | -16 mm | -25 mm | 42 mm |
| Trail | 146 mm | 156 mm | 85 mm |
| Stack | 743 mm | 786.4 mm | 610.8 mm |
| Reach | 379.8 mm | 391 mm | 399.8 mm |
| Top Tube Length | 555 mm | 572 mm | 586.5 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 440 mm | 475 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1053 mm | 1072 mm | 1087 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm |
| Standover Height | 743 mm | 775 mm | 804 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
