Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Suspension Rigid -
Brakes JAK Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tectonic T1, aluminum biaxial hydroformed and butted, BMX Race geometry, 86mm press fit BB shell, internal cable routing, 3D Forged, 10 mm dropout, tapered headtube
Suspension Fork
BOX X5 carbon, 20", aluminum tapered steerer, 20 mm x 110 mm, thru axle
Drivetrain
Crank
Xposure 2-piece, aluminum 170 mm, 24 mm hollow spindle, 4-arm with 44T chainring
Bottom Bracket
BB86 press-fit sealed bearing
Chain
KMC S1
Pedals
Mongoose, nylon
Wheels
Front Hub
Aluminum, sealed-bearing, 3/8 in bolt, 32H
Rear Hub
Aluminum, sealed-bearing cassette, 3/8 in axle, 36H, 6-bolt
Rims
Xposure Infinity-XR Disc, aluminum double wall, 30 mm ID, 32H front, 36H rear
Spokes
14G, steel, black
Tires
Arisun XLR8, 20" x 1.75", wire bead
Brakes
Brakes
JAK 7, mechanical disc, aluminum, 140mm rotor
Cockpit
Stem
Mongoose, threadless top load, 50 mm
Handlebar
Mongoose 4130, 4130 chromoly, 27.5 in width, 8 in rise
Grips
Xposure Kraton, lock-on, 140 mm
Headset
Threadless, 1-1/8" sealed integrated, taper compatible
Seat
Saddle
Xposure
Seatpost
Aluminum, 250 mm, 27.2 mm
Fit data
Geometry
