Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Titanium -
Travel Front 120mm -
Suspension Hardtail
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
FRAME
Cassette
FRAME
Crank
FRAME, Max Chain Ring 32T
Bottom Bracket
73mm English Threaded
Seat
Seatpost
30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.471 mm | 1.484 mm | 1.43 mm | 1.387 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 314 mm | 314 mm |
| Stack | 612 mm | 622 mm | 635 mm | 645 mm |
| Reach | 416 mm | 419 mm | 444 mm | 465 mm |
| Seat Tube Angle | 75 ° | 74.25 ° | 73.75 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 483 mm | 495 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 60 mm | 60 mm |
| Standover Height | 782 mm | 795 mm | 828 mm | 856 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
