Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Groupset microSHIFT, Shimano -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Promax Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Handmade Advanced Butted 7005 Aluminum with Rear Rack Mounts (brazeons), double water bottle mounts
Suspension Fork
Motobecane Unicrown CrMo Triple Butted Chromoly with one eyelet
Rear Shock
n/a
Drivetrain
Rear Derailleur
Microshift for triple front clamp-on, Shimano Sora for Triple rear
Shift Levers
Shimano ST-R221-R Precision Integrated Brake and Shifting
Cassette
Shimano Hyperglide 11-32T, 8-Speed (24 gears total)
Crank
LSC Road Aluminum, Gloss Black Finish 30x42x52 Triple / Square Taper, Sealed Bearing 68mm
Bottom Bracket
LSC Road Aluminum, Gloss Black Finish 30x42x52 Triple / Square Taper, Sealed Bearing 68mm
Chain
KMC Z9000 for 9 Speed
Wheels
Rims
Alex-R500 rim, 700c Silver anodized with Machined brake track, Formula hubs, dust sealed caged bearing with Quick Release, stainless steel spokes, radial laced front
Tires
Kenda Kwest, Road 700x28 / Presta valve
Brakes
Brakes
ProMax Aluminum Alloy Silver Finish
Brake Levers
Shimano ST-R221 Precision Integrated Brake/Shifting
Cockpit
Handlebar
Kalloy Aluminum with Comfort bend 26.0mm / Kalloy Adjustable Rise, Aluminum, threadless, 1 1/8" / Velo Dual Comfort Density
Headset
TH cage ball bearing headset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 609 mm | 611 mm | 614 mm | 620 mm | 628 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Top Tube Length | 504 mm | 520 mm | 535 mm | 540 mm | 560 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 72 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° | 71 ° | 72 ° |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1039 mm | 1041 mm | 1044 mm | 1050 mm | 1058 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 700 | 725 mm | 754 mm | 802 mm | 840 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
