Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Groupset Tiagra, Sora -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Tektro Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum alloy with Bi-Axle down tube, Integrated HeadTube, Double water bottle mounts Gallery of pics (Note: Motobecane USA is using 7005 and 6000 series frames to meet production demands. Both are engineered to be virtually identical in weight and performance)
Suspension Fork
Motobecane CrMo Cross fork (STEERER 1.125 inch) with front fender mounts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Sora front and Shimano Tiagra rear
Shift Levers
Shimano Sora 2300
Cassette
SRAM 9-speed, 11-26T
Crank
FSA Vero Aluminum Forged crankarms, 50/39/30T Chainrings, 130BCD, (170mm 49-52cm / 172.5mm 54-56cm / 175mm 58-61cm)
Bottom Bracket
FSA Vero Aluminum Forged crankarms, 50/39/30T Chainrings, 130BCD, (170mm 49-52cm / 172.5mm 54-56cm / 175mm 58-61cm)
Chain
KMC Z9000, 9 Speed
Wheels
Rims
Alex R500 w/CNC Sidewalls 6061 T6 Aluminum, Forged Aluminum hubs with standard contact sealed cage ball bearing, 14g Stainless spokes
Tires
Kenda Kwick Cross, 700 x 32c or 30c (As Available) + presta tubes / Presta Valve tubes
Brakes
Brakes
Tektro Oryx Cantilever
Brake Levers
Shimano Sora ST-3400 Brake/Shift STI 9 speed (27 gears total) AND Tektro RL570 Cross Top Levers on handlebar top section
Cockpit
Handlebar
31.8 OS butted Aluminum Road / Ritchey Logic Aluminum 1.125 inch steerer, 31.8mm OS clamp
Headset
Cane Creek, 1.125" Threadless w/ Sealed Bearing
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm | 64cm |
|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 581 mm | 591 mm | 598 mm | 601 mm | 609 mm | 619 mm | 639 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 525 mm | 529 mm | 548 mm | 560 mm | 570 mm | 590 mm | 610 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73 ° | 73 ° | 73 ° | 72 ° | 72 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm | 640 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1002 mm | 1012 mm | 1019 mm | 1022 mm | 1030 mm | 1040 mm | 1060 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 752 mm | 772 mm | 785 mm | 795 mm | 814 mm | 841 mm | 871 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
