Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain Single Speed
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Motobecane Custom Butted and Tapered Aero Profile 6066 Aluminum. Track Dropouts, 120mm rear spacing with steel dropout inserts. Drilled for rear brake mount.
Suspension Fork
Motobecane FC-770 Straight Blade Carbon Fiber, Aero-section Track fork, 1.125 threadless Aluminum steerer tube (Fork is drilled and can accept a front brake)
Rear Shock
n/a
Drivetrain
Rear Derailleur
n/a
Shift Levers
n/a
Cassette
15T Dura Ace Fixed Cog+ lockring
Crank
Shimano Dura Ace FC-7710 Track 5-arm, 144 BCD, 9/16 pedal thread, Shimano Dura Ace 49T Aluminum Track ring (3/32 width) / Shimano Dura Ace 7710, 68x109.5mm Octa-link Spline 22.2mm hollow pipe billet spindle, (49/52/54=165mm; 56/58/61=170mm) (NOTE: chainring bolts may differ on shipped bicycles)
Bottom Bracket
Shimano Dura Ace FC-7710 Track 5-arm, 144 BCD, 9/16 pedal thread, Shimano Dura Ace 49T Aluminum Track ring (3/32 width) / Shimano Dura Ace 7710, 68x109.5mm Octa-link Spline 22.2mm hollow pipe billet spindle, (49/52/54=165mm; 56/58/61=170mm) (NOTE: chainring bolts may differ on shipped bicycles)
Chain
Shimano Ultegra 6700 10 Speed
Wheels
Rims
Vuelta XRP Team SuperLite TrackSpec Black Anodized Aluminum, FLIPFLOP rear, sealed precision bearings
Tires
Vittoria Diamante PRO Light 700x23c with Presta valve tubes
Brakes
Brakes
n/a
Brake Levers
n/a
Cockpit
Handlebar
Deda Pista Track 6061 T6 Aluminum, 31.7mm clamp, 420mm width for all sizes, reach of 109mm, and a deep track drop of 173mm / Deda Quattro 6061 T6 Drop Forged Aluminum, 31.7mm clamp, Black Finish (49=90mm; 52/54/56=100mm; 58/61=110mm)
Headset
Threadless Cane Creek A46ACX Angular contact bearing with Conical Aluminum spacer
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm | 64cm |
|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 290 mm | 290 mm | 290 mm | 290 mm | 290 mm | 290 mm | 290 mm |
| Front Center | 537 mm | 547 mm | 557 mm | 560 mm | 566 mm | 576 mm | 597 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Top Tube Length | 523 mm | 540 mm | 550 mm | 560 mm | 570 mm | 590 mm | 610 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm | 640 mm |
| Head Tube Angle | 74 ° | 74 ° | 74.5 ° | 74.5 ° | 74.5 ° | 75 ° | 75 ° |
| Head Tube Length | 109 mm | 109 mm | 119 mm | 139 mm | 159 mm | 184 mm | 204 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 962 mm | 972 mm | 982 mm | 985 mm | 991 mm | 1001 mm | 1022 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 744 mm | 758 mm | 772 mm | 791 mm | 810 mm | 837 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
