Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Deore, SLX -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bigfoot 26" aluminum Norco design fat bike frame 100 mm bb fits a 26x4.0 tire 4 frame sizes SM/MED/LG/XL 170 mm OLD"
Suspension Fork
Aluminum disc mount Fat bike fork fits a 26 x 4.0 tire
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore SGS 9 speed direct mount
Front Derailleur
Shimano SLX E-type top swing/ dual pull FDM 660E
Shift Levers
Jagwire LEX housing
Cassette
Shimano CS-HG 61 9 speed cassette (12-36T)
Crank
Samos forged alloy MTB crank 32/22 T with outer guard and for fit with 100 mm BB shell 170 mm on SM / 175 mm on M/L/XL
Bottom Bracket
Samos external BB
Chain
KMC HG-53 9 speed chain
Chain Tensioner
N/A
Pedals
Wellgo alloy body / steel cage MTB pedal
Wheels
Front Hub
KT alloy disc hub 135 mm hub with 9 mm QR axle
Rear Hub
KT alloy sealed bearing disc hub 170 mm OLD w/ 9/10 sp cassette
Rims
Weinmann DHL double wall aluminum 80mm wide with drill holes presta valve
Tires
Vee Mission 26 x 4.0" folding bead fat bike tires"
Brakes
Brakes
Avid Elixer 3 hydraulic disc brake with G2 160 mm rotor
Brake Levers
Avid Elixer 3
Disk Rotors
N/A
Cockpit
Stem
Norco 3D forged alloy MTB stem 4 bolt front clamp 80 mm on SM and MED / 90 mm on LG /XL
Handlebar
Norco 6061 double butted 25 mm rise bar 740 mm width
Grips
Super light foam black
Headset
VP A-42E 1-1/8" threadless black steel"
Seat
Saddle
Norco MTB XC Trail saddle
Seatpost
Kalloy SP-368 double bolt 6061 alloy 400 mm length 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm |
| Top Tube Length | 563 mm | 583 mm | 603 mm | 623 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 696 mm | 704 mm | 709 mm | 732 mm |
| Wheels | 26" | 26" | 26" | 26" |
About this model
Bigfoot is part of the Norco Bigfoot model. Norco launched 34 bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fatbike bikes average price
If you want to purchase a solid Fatbike bike, it is important to know that the average cost is 1743$. However, this doesn’t mean that if you spend less money on a Fatbike bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Norco released this model in 2014, its price was 1415$. Comparing this to the average Fatbike bike price, we see that the price is 23.18% smaller.
Bigfoot components
Fork material
Bigfoot has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
When it comes to wheels, the Bigfoot bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
